BLUE PAPER ONNA · 202218 | ORBEA ORBEA | 19TECHNICAL MANUAL 19
EN
FRAME MATERIAL Aluminum 6061
RECOMMENDED USE MTB Sport. ASTM Condition 3 Sport
SIZES XS (27.5), S (27.5), S (29), M (29), L (29), XL (29)
FORK TRAVEL 100mm
MAXIMUM FORK LENGHT
(AXLE-TO-CROWN)
27.5" sizes = 500mm
29" sizes = 519mm
FORK OFFSET
27.5" sizes = 42mm
29" sizes = 46-51mm
HEADSET
Semi integrated. 1-1/8" - 1-1/2"
1-1/8" straight tube forks with lower reducer. See headset section.
MAXIMUM NUMBER OF HEADSET
SPACERS
20mm
BOTTOM BRACKET
BSA 68mm (Threaded)
Square tapered bottom bracket axle length: 124.5mm
BB SHELL WIDTH 68mm
CHAINLINE 49mm
WHEEL SIZE
XS (27.5) and S (27.5) = 27.5"
S (29), M, L, XL = 29"
MAXIMUM TYRE WIDTH 2.4"
REAR AXLE/HUB STANDARD QR (135x9mm)
SEATPOST DIAMETER 27.2mm
SEATPOST CLAMP DIAMETER
31.8mm
MAXIMUM SEATPOST INSERTION
XS (27.5) 300mm
S (27.5) 170mm
S (29) 170mm
M (29) 205mm
L (29) 245mm
XL (29)
315mm
DROPPER SEATPOST INTERNAL
CABLING COMPATIBLE
Yes
FRONT DERAILLEUR Down-Pull. Clamp 31.8mm
FRONT DERAILLEUR ANGLE 68.5º
MAXIMUM CHAINRING SIZE 2X 38T
MAXIMUM CHAINRING SIZE 1X 34T
BRAKES DISC*
BRAKE CALIPER STANDARD POST MOUNT
REAR ROTOR MAXIMUM SIZE 160mm
REAR ROTOR MINIMUM SIZE 160mm
FRONT ROTOR MAXIMUM SIZE Depends on fork. Orbea assemblies 160mm
ICGS05 No
CABLING
Rear derailleur and rear brake: Internal through DT, external on chainstays. Full housing
Front derailleur: Internal through DT
Front brake: External
Dropper seatpost: Internal through DT and seat tube. Full housing
BOTTLE HOLDER
1 on size XS
2 on rest of sizes
DRIVETRAIN COMPATIBILITY 8S-11S (1X and 2X). MTB. 135mm QR dropouts
COMPATIBLE SHIMANO DI2 No
COMPATIBLE SRAM AXS No
COMPATIBLE WITH TRAILER Yes. 135mm QR axle. Consult aftermarket options
COMPATIBLE WITH REAR RACK Yes. Threads on chainstays and seatstays
COMPATIBLE WITH CHILDSEAT Yes. Only rear rack models. Consult aftermarket options
POWERMETER COMPATIBLE No
MAXIMUM STRUCTURAL WEIGHT LIMIT
(RIDER+GEAR+LUGGAGE)
Consult the Orbea Products Structural Weight Limit document on Orbea´s website
* Not all calipers and rotors in the market are compatible with all frames.
All componets specicated from Orbea have been tested. For aftermarket options, check componentes dimensions and tolerances
befores purchasing.
TECHNICAL SPECIFICATIONS
