Step 4:
Install the saddle (7) to the Horizontal seal post (31) with Multifunctional wrench. Then tighten the
Horizontal seal post (31) on the Saddle supporting tube (6) with Flat washer (19), Knob nut (20).
Finally, insert the Saddle supporting tube (6) to the Main frame (1) and tighten with Spring Knob
(28) .You can adjust the Spring Knob (28) to appropriate height which is suitable for you.
Note: Before use the bike, please make sure that the Saddle (7) have locking on the Horizontal
seal post (31).
Step 5:
Attach the Pedals (10L/R) to the Cranks (35L/R) of the Main Frame (1).
Note: The left pedal (10L) should be tighten in the counterclockwise direction, the right pedal (10R)
should be tighten in the clockwise direction.
