PARTS LIST
Part No. Description Qty Part No. Description Qty
1 Main frame 1 54 Seat 1
2 Front stabilizer 1 55 Adapter 1
3 Rear stabilizer 1 56 Crank Cover 2
4 Handlebar post 1 57 Flange bolt 2
5 Fixed handlebar 1 58L/R Chain cover 1pr.
6 Nylon nut M8 2 59 Hex nut 2
7 Flat washer D8xΦ16x1.5 6 60 Adjusting bolt 2
8 Roller 2 61 U-shape washer 2
9 Inner hexagon bolt M8x40xL12 2 62 Hex nut 2
10 End cap 2 63 Nut 2
11 Hex nut M10 5 64 Bushing 2
12 Adjusting pad 5 65 Cone bushing 1
13 Inner hexagon bolt M8xL58 4 66 Flywheel axle 1
14 Spring washer D8 8 67 Flywheel 1
15 Arc washer d8x2xΦ25xR39 4 68 Motor 1
16 End cap 2 69 Spring washer 1
17L/R Crank 1 pr. 70 Bearing 2
18L/R Pedal 1 pr. 71 Inner hexagon bolt 3
19 Inner hexagon bolt M8x15 8 72 Belt wheel 1
20 Arc washer d8xR20 2 73 Mid-axle 1
21 Sensor wire 1 74 Belt 1
22 Extension wire 1 75 Small belt wheel 1
23L/R Protective guard 1 pr. 76 Sensor 1
24 Screw 34 77 Cushion 2
25a/b Protective guard 1 pr. 78L/R Track Cover 1pr.
26 Inner hexagon bolt M8x90 2 79 Square End cap 1 1
27
lifting handle
1 80 Square End cap 2 1
28 Inner hexagon bolt M8x12 16 81 Hex bolt 1
29 Backrest 1 82 Hex nut 2
30 Round end cap 1 83 Hex bolt 2
31 Screw 1 84 Spring washer 2
32 Plastic handle knob 1 85 Flat washer 2
33 Spacer 1 86 Spring washer 2
34 Flat washer 1 87 Tension spring 1
35 Foam grip 2 88 Magnetic holder 1
36 Extension pulse wire 1 2 89 Magnet 10
37 Extension pulse wire 2 2 90 Magnetic holder axle 1
38 Computer 1 91 Nylon nut 4
39 eccentric shaft 1 92 Roller 4
40 Inner hexagon bolt M6x10 4 93 Bushing 4
41 Handle 1 94 Inner hexagon bolt 4
42 Foam grip 1 95 Seat holder 1
43 Flat washer D8xΦ19x1.5 12 96 Spring washer 1
44 Extension pulse wire 3 2 97 Alloy bushing 1
45 Pulse wire 2 98 Handle holder 1
46 Fixed bracket 1 99 Alloy bushing 1
47 Protective guard 1 100 Upper press block 1
