10
CLEANING THE PRE-FILTER
CLEANING THE TRUMAN COLLECTOR CELL
1. Unplug the air purifier.
2. Open the Cover by gently pulling from the top corners.
3. Pull the Pre-Filter straight out of the Cabinet.
4. Thoroughly rinse the Pre-Filter and let it air dry before placing it back in the Cabinet. Do
not use heated or compressed air as part of the drying process.
5. Slide the Pre-Filter back into the unit.
6. Close the Cover securely.
1. Unplug the air purifier.
2. Open the Cover by gently pulling from the top corners.
3. Remove the Truman Cell
®
® by unlocking top and
bottom knobs and pulling straight out.
4. Separate the Truman Cell®
®
from the Wire Assembly
for easier access to each during cleaning.
1
2
3
3
Note: The Truman Cell
®
may require more frequent cleaning
if “arcing” occurs. Arcing is a sharp snapping sound that
occurs when large particles are collected in the Truman Cell
®
.
If prolonged or continuous arcing occurs the Truman Cell
®
should be cleaned.
1
