6 | Increase Quality through Interaction with the Field
5. Unscrew Dirt Tube Collar (8). Use special mul-tool #72591-01 to prevent cosmec damage.
6. Remove Dirt Tube from base at the Fan Housing Assembly (41) by pulling straight up.
Dirt Tube (29)
Dirt Tube Collar (8)
Mul-tool #72591-01
Dirt Tube Collar
O-ring (9)
Base with upper
assembly removed
Non RF Unit Shown
