Oreck Magnesium LW100 Series

4 | Increase Quality through Interaction with the Field
3. Remove Power Buon Bracket (35) and Handle Switch Mount (34) located behind the disposable
bag. Remove the ve screws on the Handle Switch Mount Bracket (34) to detach both. The Power to
Switch to PCB Harness (37) is located behind the Power Buon.
Power Buon and spring (36) located in Power
Buon Bracket (35) Non-RF Units Only.
Power Buon (37)
and Switch Bracket
(21) Non-RF Units
Only.
Handle Switch Mount
Bracket (34) All Units
