CLEANING THE CATALYTIC OXYGENATOR
CLEANING THE EXHAUST GRILLE
1. Unplug the air purifier and lay it on its side with the hinged cover on top.
2. Open the Top Cover by pressing the Cover Release button.
3. Remove the Odor Absorber, Pre-Filter and Collector Cell.
4. Vacuum the front face of the filter with a soft-brush attachment only. Do not use liquids to clean.
5. Replace the Odor Absorber, Collector Cell and Pre-Filter.
6. Close the Top Cover securely.
1. Remove the Cleaning Brush from the storage slot located under the Top Cover.
2. Brush away debris that has collected between the Grille Slots.
3. Return the Cleaning Brush to the storage slot.
1
2
4
3
1
2
TO REDUCE THE RISK OF ELECTRIC SHOCK— UNPLUG BEFORE CLEANING OR SERVICING
WARNING!
