16
Maintenance — Adjusting or Replacing Brushroll
2
Lay the unit at to access
the power head nozzle.
Remove the 7 screws to take
off the baseplate from the
power head.
1
Your Oreck
®
unit comes with
the brushroll assembled in the
“NORMAL” position (multiple
notches showing on top edge).
As the brushroll wears it can be
adjusted for longer life.
3
Remove the brushroll
belt and brushroll from the
holding channels inside of
the power head nozzle.
4
When worn, rotate both
plastic black endcaps at the
ends of the brushroll to show
a single notch “SPECIAL”
position. Insert back into the
holding channels of the power
head nozzle.
NORMAL
SPECIAL
WARNING TO REDUCE THE RISK OF ELECTRIC SHOCK OR INJURY FROM MOVING PARTS - UNPLUG
BEFORE CLEANING OR SERVICING. DO NOT USE VACUUM WITHOUT THE FILTRATION BAG IN PLACE.
