Part Numbers Listing: XL21-600ECC, XL21-600ECB, XL21-700ECC, XL21-700ECB, XL21-700ECP, XL21-700ECT
Type 1-4 Units
# Item Order # Qty. Pk.
6
27 Pin Latch 52033P1 1 1
28 XL21-600ECC / XL21-700ECC: Door, Belt Access, Creme 77010-02-453 1 1
XL21-600ECB / XL21-700ECB / XL21-700ECP: Door, 77010-02-0327 1 1
Belt Access, Black
XL21-700ECT: Door, Belt Access, Lt. Gray 77010-02-436 1 1
29 Detent 77017-01 1 1
30 Reflector Assembly, Includes #25, 78, 79 09-77071-02 1 1
30a Light Mount (Not Shown, LED Units Only) 77247-01-0000 1 1
31 XL21-600ECC / XL21-700ECC: Cover, Light LED, Creme 77034-01-453 1 1
XL21-600ECB / XL21-700ECB / XL21-700ECP: Cover, 77034-01-0327 1 1
Light LED, Black
32 Bumper, Main, Gray 77012-01-0384 1 1
33 Bumper, Side, Gray 77013-01-0384 1 1
34 Felt Seal, Motor 75117-01M 1 100
35 Seal, Inlet Foam, Black 77031-01 2 1
36 Seal, Felt Inlet, White 77032-01 1 1
37 Seal, Power Nozzle 5” 77043-01 1 1
38 Seal Power Nozzle 1” 77043-02 1 1
39 Strain Relief, Square 03-00494-01 1 1
40 Motor Assembly Kit
Do not use with #27 (latch pin).
09-77038-02 1 1
41 Motor Brush & Spring Kit 77114-01 2 2
42 Drive Belt, (3 Pk.) 0300604 1 3
42a Drive Belt, Single 75024-01 1 1
43 Brush Roll Assembly 77090-02 1 1
44 XL21-600ECC / XL21-700ECC: Door, Exhaust Filter, Creme 77044-01-453 1 1
XL21-600ECB / XL21-700ECB / XL21-700ECP: Door, Exhaust 77044-01-0327 1 1
Filter, Black
X L 2 1 - 7 0 0 E C T: Door, Exhaust Filter, Lt. Gray 77044-01-436 1 1
45 Housing, Exhaust Filter 77045-01-0327 1 1
46 Exhaust Filter 77022-01 1 1
47 Base Plate Assembly w/Squeegee, Channel, Wheels 09-77127-03 1 1
Includes #48, 49, 50, 51, 52, 53, 54, 71
47a Base Plate Assembly w/ Channel, Squeegee 09-77092-05 1 1
48 Channel/Squeegee 77046-02 1 1
49 Sock Guard 77055-01 1 1
50 Edge Brush Assembly, Blade 77018-01 2 1
50a Edge Brush Assembly, Tufted 77134-02 2 1
51 Wheel, Front 77050-02-0327 2 1
52 Axle, Front Wheel 03-00583-01 2 1
53 Axle, Rear Wheel 03-00584-01 2 1
54 Rear Wheel, Black 75187-02-0327 2 1
55 Seal, Motor Mount 77122-01 1 1
56 Static Wire 77027-02 1 1
57 Switch, 2 Speed
Type 1 Units Only
75320-01 1 1
Switch, 2 Speed
Type 2, 3 & 4 Units Only
77155-01 1 1
To Next Page
