11
1
4
2
76
8 9
3
5
10
12 13 14 15 4 16 17 18
20
19
21
22
21
22
23
Power button
Power LED ring
One piece aluminum chassis
VFD/IR acryl window
Top panel
Optical disk drive (ODD) bezel
Soft-eject access panel
I/O ports/multi-format card reader
ODD eject button
Door latch
+
Fixing point for HM100 (see 23)
Intake vent
I/O ports/card reader PCB
ODD cage
4th HD mount bracket
Philips IR controller* fixing point
VF210 VFD/IR module
Primary hard drive cage
Side intake vent
92mm low dB fan
Top panel fixing screw
80mm low dB fan
+
HM100 hard drive mount
(allows a 5th HD to be installed)
+
optional accessory
*part of an optional IR kit (IR221)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
S16V overview
These are the main features and
controls of the S16V htpc enclosure.
6
