DSP3 -700 AMPLIFIER INSTALLATION USER MANUAL
2
Amplifier Presets
PRESET NUMBER PRESET NAME
SUB MODEL
NUMBER
SAT MODEL
NUMBER
SYSTEM DESCRIPTION
1 DSP O None None
All DSP Bypassed, All inputs
and outputs linked, three mono
channels
2 0 LS44 None LS44
All three channels have the same
DSP tuned for LS44
3 0 LS64 None LS64
All three channels have the same
DSP tuned for LS64
4 0 OS54 None OS54
All three channels have the same
DSP tuned for OS54
5 0 OS56 None OS56
All three channels have the same
DSP tuned for OS56
6 0 OS64 None OS64
All three channels have the same
DSP tuned for OS64
7 0 OS66 None OS66
All three channels have the same
DSP tuned for OS66
8 8 LS44 OSUB8 LS44
Sub channel tuned for OSUB8, le
and right channels tuned for LS44
9 8 LS64 OSUB8 LS64
Sub channel tuned for OSUB8, le
and right channels tuned for LS64
10 8 STA0 OSUB8 None
All three channels tuned for OSUB8
(no satellites)
11 10LS44 OSUB10 LS44
Sub channel tuned for OSUB10, le
and right channels tuned for LS44
12 10LS64 OSUB10 LS64
Sub channel tuned for OSUB10, le
and right channels tuned for LS64
13 10SAT0 OSUB10 None
All three channels tuned for
OSUB10 (no satellites)
14 12LS44 OSUB12 LS44
Sub channel tuned for OSUB12, le
and right channels tuned for LS44
15 12LS64 OSUB12 LS64
Sub channel tuned for OSUB12, le
and right channels tuned for LS64
