Orion Power Systems DC1000RT - Technical Specifications; UPS Model Specifications

22
MODEL
DC1000RT DC1000RTX DC1500RT DC1500RTX DC2000RT DC2000RTX DC3000RT DC3000RTX
VA 1000 VA 1000 VA 1500 VA 1500 VA 2000 VA 2000 VA 3000 VA 3000 VA
Capacity
W 800 W 800W 1200 W 1200 W 1600 W 1600 W 2400 W 2400 W
INPUT
Rated
voltage
100VAC-120VAC
Low Line
Transfer
80 VAC/70 VAC/60 VAC/55 VAC ± 5 %
(based on load percentage 100%-80% / 80%-70% / 70%-60% / 60%-0)
Low Line
Comeback
85 VAC/75 VAC/65 VAC/60 VAC ± 5 %
High Line
Transfer
150 VAC ± 5 %
Voltage
Range
High Line
Comeback
142 VAC ± 5 %
Frequency Range 40Hz ~ 70Hz
Power Factor
≧0.99 @normal voltage
OUTPUT
Output Voltage 100*/110*/115*/120VAC
AC Voltage Regulation ± 1%
Frequency Range 47 ~ 53 Hz or 57 ~ 63 Hz (Synchronized Range)
Frequency Range
50Hz  0.5% or 60Hz  0.5% (Bat. Mode)
Current Crest Ratio (CF) 5:1 (max.)
Harmonic Distortion
(THDU)
≦ 2% (Linear load)
8% max (Batt. mode before shut down)
≦ 2% (Linear load)
8% max (Batt. mode before shut down)
AC to DC Zero
Transfer
Time
Inverter to
Bypass
4 ms (Typical)
Waveform (Batt. Mode) Pure Sine wave
EFFICIENCY
AC Mode
86% (typical), 88% (peak) 88% (typical), 90% (peak)
Battery Mode
83% (typical), 86% (peak) 85% (typical), 88% (peak)
BATTERY
Battery Type 12V/9Ah 12V/9Ah 12V/9Ah 12V/9Ah
Numbers 2 3 4 6
Typical Recharge Time 4 hours recover to 90% capacity (for standard model only)
Charging Current (max.) 1 A 1 A 1 A 1 A
Charging Voltage 27.4 VDC ± 1% 41.1 VDC ± 1% 54.7 VDC ± 1% 82.1VDC ± 1%
INDICATORS
LCD UPS status, Load level, Battery level, Input/Output/battery info, Discharge time and Fault indicators
ALARM
Battery Mode Sounding every 4 seconds
Low Battery Sounding every second
Overload Sounding twice every second
Fault Continuously sounding
PHYSICAL
Dimension, DxWxH (mm) 380 x 438 x 88 480 x 438 x 88 480 x 438 x 88 600 x 438 x 88
Net Weight (kgs) 13.2 18.9 21.4 29.6
ENVIRONMENT
Humidity 20-90 % RH @ 0- 40°C (non-condensing)
Noise Level Less than 50dBA @ 1 Meter
MANAGEMENT
Smart RS-232/USB Supports Windows 2000/2003/XP/Vista/2008/7, Linux, Unix, and MAC
Optional SNMP Power management from SNMP manager and web browser
*Derate capacity to 95% when the output voltage is adjusted to 115VAC, derate capacity to 90% when the output voltage is
adjusted to 110VAC and derate capacity to 80% when the output voltage is adjusted to 100VAC.
6. Specifications
