5
/
12
2. INTERFACES, CONTROLS & SETTINGS
Interfaces instruction
DC12V The main power input of monitor, DC12V
HDMI IN
T
he HDMI Input Source
VGA IN The VGA Input Source
BNC 1(CVBS) IN The BNC Input for CVBS Source
BNC 2(CVBS) Out The BNC Looping output for CVBS Source
