6
© 2005 Directed Electronics—all rights reserved
SPECIFICATIONS
1. Continuous 4W load 20Hz to 250Hz, < 1% THD, with input voltage at 14.4VDC.
2. Continuous 1W load 20Hz to 250Hz, < 1% THD, with input voltage at 14.4VDC.
Amplifier Section HCCA-D600
Power Output 4W (Watts)
1
150 x 1
Power Output 2W (Watts)
2
200 x 1
Power Output 1W (Watts)
300 x 1
Amplifier Efficiency
> 70% into 1W load at max. power
Externally Bridgeable yes
Remote Bass Function yes (optional HP-RB1 not supplied)
Distortion at Rated Power < 1.0% THD+N
Frequency Response 20Hz to 250Hz ±2.5dB
Linear Bandwidth 10Hz to 500Hz ±3dB
Damping Factor > 200
Input Sensitivity 150mV to 5V rms
Supply Voltage Range 9 to 16V
Protection
thermal, DC offset, reverse polarity,
short protection, under-voltage, over-
voltage
Terminal Wire Gauge
Power 0/1 AWG, Remote 12 AWG,
Ground 0/1AWG, Speaker 12 AWG
Input Impedance
20kW
Fuse Type (1) 40 Amp ATC
Dimensions 13"x10.5"x2.3"
Weight 8 lbs.
Crossover Section
Low Pass Crossover Continuously variable (30-250Hz)
Infrasonic Filter
Selectable On/Off
24dB/Octave -6dB at 20Hz
Intelli-Bass 0–18dB boost
