Orion HCCA12200.2 User Manual

Amplifier Section HCCA1000.4 HCCA1500.4 HCCA2000.4 HCCA3000.4H HCCA4000.4H
RMS WATTS @ 4 OHM STEREO 12.6 V @ 0.05 Thd 4 x 150W 4 x 250W 4 x 300W 4 x 450W 4 x 600W
RMS WATTS @ 2 OHM STEREO 12.6 V @ 0.05 Thd 4 x 250W 4 x 375W 4 x 500W 4 x 750W 4 x 1000W
RMS WATTS @ 4 OHM BRIDGE 12.6 V @ 0.05 Thd 2 x 500W 2 x 750W 2 x 1000W 2 x 1500W 2 x2000W
RMS WATTS @ 4 OHM STEREO 14.4 V @ 0.05 Thd 4 x 216W 4 x 296W 4 x 392W 4 x 580W 4 x 844W
RMS WATTS @ 2 OHM STEREO 14.4 V @ 0.05 Thd 4 x 337W 4 x 472W 4 x 620W 4 x 823W 4 x 1125W
RMS WAT
TS @ 4 OHM BRIDGE 14.4 V @ 0.05 Thd 2 x 670W 2 x 967W 2 x1220W 2 x 1625W 2 x 2250W
TOTAL POWER WATTS NOMINAL 12.6 V @ 0.05 Thd 2000W 3000W 4000W 6000W 8000W
TOTAL POWER WATTS NOMINAL 14.4 V @ 0.05 Thd 2680W 3868W 4400W 6500W 9000W
MAX MUSIC POWER 4000W 6000W 8000W 12000W 16000W
Amplifier Efficiency
Signal to Noise ratio at rated output power and lowest
Remote Gain Function
Distortion at Rated Power
Frequency Response
Linear Bandwidth
Damping Factor
Input Sensitivity(rms)
Supply Voltage Range
Protection
Input Impedance
Balanced input (CMRR)
Dimensions(inches) 15.0 x 11.7 x 2.8 16.6 x 11.7 x 2.8 21.3 x 11.7 x 2.8 29.2 x 11.7 x 2.8 33.1 x 11.7 x 2.8
High Pass Crossover
Low Pass Crossover
Phase shift control
Bass Boost
thermal, DC offset, short protection, undervoltage, over-voltage
200mV to 4V
9 to 16V
0-18dB variable
Power 0 AWG
Remote 10 AWG
Ground 4 AWG
Speaker 10 AWG
20㏀
Terminal Wire Gauge
> 67% into 2 load at max. power
> 95dB
Yes
0.005% THD+N
20 Hz to 35kHz +/- 1 dB
20 Hz to 65kHz +/- 3 dB
> 100
Yes
Continuously variable (40-1.25kHz/400-12.5kHz)
Continuously variable (40-300Hz)
0˚ to 180˚
Crossover Section

Orion HCCA12200.2 Specifications

General

Brand	Orion
Model	HCCA12200.2
Category	Car Amplifier
Language	English
