Orion HCCA12200.2 User Manual

Amplifier Section HCCA1200.2 HCCA1500.2 HCCA2000.2 HCCA3000.2H HCCA4000.2H
RMS WATTS @ 4 OHM STEREO 12.6 V @ 0.05 Thd 2 x 400W 2 x 500W 2 x 600W 2 x 900W 2 x 1200W
RMS WATTS @ 2 OHM STEREO 12.6 V @ 0.05 Thd 2 x 600W 2 x 750W 2 x 1000W 2 x 1500W 2 x 2000W
RMS WATTS @ 4 OHM BRIDGE 12.6 V @ 0.05 Thd 1200W 1500W 2000W 3000W 4000W
RMS WATTS @ 4 OHM STEREO 14.4 V @ 0.05 Thd 2 x 478W 2 x 552W 2 x 728W 2 x 1040W 2 x 150
9W
RMS WATTS @ 2 OHM STEREO 14.4 V @ 0.05 Thd 2 x 770W 2 x 922W 2 x 1185W 2 x 1610W 2 x 2202W
RMS WAT
TS @ 4 OHM BRIDGE 14.4 V @ 0.05 Thd 1525W 1866W 2345W 3320W 4328W
TOTAL POWER WATTS NOMINAL 12.6 V @ 0.05 Thd 2400W 3000W 4000W 6000W 8000W
TOTAL POWER WATTS NOMINAL 14.4 V @ 0.05 Thd 3000W 3800W 4800W 6600W 8650W
MAX MUSIC POWER 4800W 6000W 8000W 12000W 16000W
Amplifier Efficiency
Signal to Noise ratio at rated output power and lowest
impedance
Remote Gain Function
Distortion at Rated Power
Frequency Response
Linear Bandwidth
Damping Factor
Input Sensitivity(rms)
Supply Voltage Range
Protection
Input Impedance
Balanced input (CMRR)
Dimensions(inches) 15.0 x 11.7 x 2.8 16.6 x 11.7 x 2.8 21.3 x 11.7 x 2.8 29.2 x 11.7 x 2.8 33.1 x 11.7 x 2.8
High Pass Crossover
Low Pass Crossover
Phase shift control
Bass Boost
Terminal Wire Gauge
Yes
Continuously variable (40-1.25kHz/400-12.5kHz)
Continuously variable (40-300Hz)
0˚ to 180˚
thermal, DC offset, short protection, undervoltage, over-voltage
Power 0 AWG
Remote 10 AWG
Ground 4 AWG
Speaker 10 AWG
20㏀
> 67% into 2 load at max. power
> 95dB
Yes
0.005% THD+N
10 Hz to 35kHz +/- 1 dB
20 Hz to 65kHz +/- 3 dB
> 100
200mV to 4V
9 to 16V
0-18dB variable
Crossover Section

Orion HCCA12200.2 Specifications

General

Brand	Orion
Model	HCCA12200.2
Category	Car Amplifier
Language	English
