SPECIFICATIONS
3
HCCA CLASS A/B AMPLIFIERS
ORION HCCA 2CH&4CH HCCA1500.2 HCCA2000.2. HCCA1000.4 HCCA1500.4 HCCA2000.4
POWER
4-ohm 2 x 500W 2 x 600W 4 x 150W 4 x 250W 4 x 300W
2-ohm 2 x 750W 2 x 1000W 4 x 250W 4 x 375W 4 x 500W
4-ohm BRIDGE 1500W 2000W 2 x 500W 2 x 750W 2 x 1000W
Gain Control 200mV~6V
Bass-Boost 0dB~18dB
HIGH PASS
FILTER
x1 50Hz~1.5kHz
x10 500Hz~15kHz
LOW PASS FILTER 20Hz~250Hz
PHASE 0~180 degrees
Remote Gain Control yes
S/N >90dB
Damping >200
Recommended Fuse Rating 150A 200A 80A 150A 200A
Dimensions (mm) 400x302x80 520x302x80 400x302x80 440x302x80 520x302x80
Dimensions (inches) 15.75x11.89x3.15 20.47x11.89x3.15 15.75x11.89x3.15 17.32x11.89x3.15 20.47x11.89x3.15
HCCA CLASS-D MONO-BLOCK AMPLIFIERS
ORION HCCA MONO-BLOCK HCCA3000.1DSPLX HCCA5000.1DSPLX HCCA8000.1DSPLX HCCA12500.1DSPLX HCCA17000.1DSPLX
POWER
4-ohm 1500W 2300W 2900W 4300W 6000W
2-ohm 2800W 3600W 5000W 7500W 10500W
1-ohm 4500W 5800W 8500W 12700W 17500W
2-ohm LINKED 9000W 11600W 17000W 25400W 35000W
Gain Control 200mV~6V
Bass-Boost 0dB~18dB
SUBSONIC FILTER 10Hz~40Hz
LOW PASS FILTER 40Hz~300Hz
PHASE 0~180 degrees
Remote Gain Control yes
S/N >90dB
Damping >200
Recommended Fuse Rating 350A 500A 750A 1100A 1500A
Dimensions (mm) 480x302x80 520x302x80 610x302x80 860x302x80 960x302x80
Dimensions (inches) 18.89x11.89x3.15 20.47x11.89x3.15 24.02x11.89x3.15 33.85x11.89x3.15 37.79x11.89x3.15
