2
Figure 1. Overview of SkyQuest XTg Dobsonian (12" shown)
Navigation knob
Altitude motor
housing
12.5mm Illuminated
Plössl 1.25" eyepiece
Eyepiece rack
Dobsonian base
Polyethylene foam
dust guard
EZ Finder II
28mm DeepView
2" eyepiece
2" Dual-speed
Crayford focuser
Optical tube
Handle
Handle
Tube
connecting knob
GoTo hand
controller
Azimuth
motor housing
(not shown)
