5. Specifications Camera EMOS BroadR-Reach
30°/60°/90°/120°/180°
Description
Lens speci ed Hor. lens angle Ver. lens angle
EMOS 180° BroadR-Reach 180° 130°
EMOS 120° BroadR-Reach 120° 91°
EMOS 90° BroadR-Reach 90° 68°
EMOS 60° BroadR-Reach 60° 45°
EMOS 30° BroadR-Reach 30° 22°
Sensor
Sensor element: High resolution 1/3” CMOS rolling shutter, 1280H x 960V.
Video image:60fps at 720p SDR, 45fps at 960p SDR image processing and
56fps at 720p HDR, 43fps at 960p HDR image processing.
Protocols: RTP (MJPEG RFC2435 and h.264 RFC6184) over UDP,
ISO17215-2014, IEEE1722 (AVB).
IP address: DHCPv4 or static IPv4 (IPv6 possible).
Latency: <100ms depending on hardware processing platform (50ms
demonstrated on Orlaco hardware).
Light sensitivity: responsitivity 5,5V/lux-sec, Low light feature (<0,1Lux).
High dynamic range: >115dB.
Compression: MJPEG, H.264 (High 10 intra profile encoding).
Interface: 100Mb/s (BroadR-Reach).
Overall shielding connected to connector housing.
