Orolia SecureSync 2400 Field Installation Guide

Technical Note • May 4, 2021
Page 6
SecureSync 2400 Option Card Field Installation Guide
c.
Identify your installation steps via the table below.
i.
Find your
part number in the left-hand column. Some cards require special installation steps or spe-
cific locations.
ii.
Choose your
Installation Location (as determined above).
iii.
If using slots 4 or 6, select either the
Bottom Slot row "empty" or "populated"
iv.
Note or highlight the
PROCEDURE STEPS [x] for your installation scenario and follow the pro-
cedure step by step.
Table 1-2:
Installation steps
Part No. Option Card Card Function
Installation
Location
Bottom Slot PROCEDURE STEPS [x]
1204-
08
1204-
26
1204-
1C
1204-
0C
Frequency output Slot 1 or 2 (1), 2, 3, 4, 8, 11, (12)
Slot 3 or 5 (1), 2, 3, 5, 8, 11, (12)
Slot 2 or 4 empty (1), 2, 3, 6, 8, 11, (12)
populated (1), 2, 3, 7, 8, 11, (12)
1204-
0F
Alarm relay Slot 1 or 2 (1), 2, 3, 4, 9, 11, (12)
Slot 3 or 5 (1), 2, 3, 5, 9, 11, (12)
Slot 2 or 4 empty (1), 2, 3, 6, 9, 11, (12)
populated (1), 2, 3, 7, 9, 11, (12)
1204-
1F
NEMA-Compliant Slots 1 & 2 (1), 2, 3, 4, 10, 11, (12)
1204-
49
1204-
4A
Gb Ethernet and NTP Networking Slot 1 or 2 (1), 2, 3, 4, 11, (12)
All other Part No.'s (miscellaneous) Slot 1 or 2 (1), 2, 3, 4, 11, (12)
Slot 3 or 5 (1), 2, 3, 5, 11, (12)
Slot 2 or 4 empty (1), 2, 3, 6, 11, (12)
populated (1), 2, 3, 7, 11, (12)
Note: All installation situations include steps 1 (unpacking), 2 (save reference configuration), 3
(determine installation procedure), 11 (verifying hardware detection and software upgrade) and 12
(restoring configurations)
Steps 4 through 10 of this installation procedure should only be performed if your installation loc-
ation or card requires it.
