2 ORU KAYAK | ASSEMBLY GUIDE
Shoulder strap: Used to
carry the kayak when in
box form. Stow behind the
backrest while kayaking.
Seam channels (2): Help
seal the deck seam.
Stern (back) bulkhead:
Provides structural
rigidity.
Adjustable ergonomic
backrest: Combines
adjustable back support
and structural rigidity.
Seat pad: Tucks under the
shock cord in the floorboard.
Deck straps: Stores
extra gear on the
kayak deck.
Spare parts: Extra
hardware for repairs or
replacements.
1
2
3
4
5 7
6
Parts: loose components
2
2 SEAM
CHANNELS
1
SHOULDER
STRAP
3
STERN
BULKHEAD
2 DECK
STRAPS
64
BACKREST
5
SEAT PAD
SPARE
PARTS
