6. Specifications
MODEL ORVALDI V1000(L) online V1500(L) online V2000(L) online V3000(L) online
Capacity VA/W 1000 VA/800 W 1500 VA/1200 W 2000 VA/1600 W 3000 VA/2400 W
INPUT
Low Line Transfer
160 VAC/140 VAC/120 VAC/110 VAC ± 5%
(based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % - 0)
Low Line Comeback 170 VAC /150 VAC/ 130 VAC /120 VAC± 5 %
High Line Transfer 300 VAC ± 5 %
Voltage
Range
High Line Comeback 290 VAC ± 5 %
Frequency Range 45Hz ~ 55 Hz or 56Hz ~ 65 Hz
Power Factor
≧0.99 @normal voltage
OUTPUT
Output voltage 200/208/220/230/240VAC
AC Voltage Regulation ± 1%
Frequency Range (Synchronized
Range)
48 ~ 52 Hz or 58 ~ 62 Hz
Frequency Range
(Batt. Mode)
50 Hz ± 0.2 Hz or 60Hz ± 0.2 Hz
Current Crest Ratio (CF) 3:1 (max.)
Harmonic Distortion (THDU)
≦ 2% (Linear load)
8%max (Bat mode before shut down)
AC to DC Zero
Transfer
Time
Inverter to Bypass 4 ms (Typical)
Waveform (Batt. Mode) Pure Sinewave
EFFICIENCY
AC Mode 86% (typical), 88% (peak) 88% (typical), 90% (peak)
Battery Mode 83% (typical), 86% (peak) 85% (typical), 88% (peak)
BATTERY
Battery Type 12V/9Ah 12V/7Ah 12V/9Ah 12V/9Ah 12V/7Ah 12V/9Ah
Numbers 2 3* 3 4 6* 6
Recharge Time 4 hours recover to 90% capacity (Typical)
Charging Current 1 A (max.)
Standard
Model
Charging Voltage
27.4 VDC
± 1%
41.1 VDC
± 1%
41.1 VDC ± 1%
54.8VDC
± 1%
82.1VDC
± 1%
82.1VDC ± 1%
Battery Type &
Numbers
Depending on the capacity of external batteries
Charging Current 8.0 A(max.)
Long-run
Model
Charging Voltage
27.4 VDC
± 1%
41.1 VDC
± 1%
41.1 VDC ± 1%
54.8VDC
± 1%
82.1VDC
± 1%
82.1VDC± 1%
PHYSICAL
Dimension, DxWxH
(mm)
380 x 438
x 88
480 x 438
x 88
480 x 438 x 88
480 x 438
x 88
600 x 438
x 88
600 x 438 x 88
Standard
Model
Net Weight (kgs) 13.2 18.4 18.5 20.6 25.7 29
Dimension, DxWxH
(mm)
380 x 438
x 88
480 x 438
x 88
480 x 438 x 88
480 x 438
x 88
600 x 438
x 88
600 x 438 x 88
Long-run
Model
Net Weight (kgs) 9.1 11.3 10.7 11.3 14.6 14.8
ENVIRONMENT
Humidity 20-90 % RH @ 0- 40°C (non-condensing)
Noise Level Less than 50dBA @ 1 Meter
MANAGEMENT
Smart RS-232/USB Supports Windows 2000/2003/XP/Vista/2008/7, Linux, Unix, and MAC
Optional SNMP Power management from SNMP manager and web browser
*In LV system, only 12V/7Ah x 3 for 1K model and 12V/7Ah x 6 for 2K model available.
NOTE: Derate capacity to 60% of capacity in Frequency converter mode and to 80% when the output voltage is adjusted to
200/208VAC
