Orwak 3110 User Manual

3110 (mm)
1365
680
866
704
1990
458550
648
98
OK
2011-11-14
3115
1000002-00
380 kg
~950 mm
~1993 mm
(490 3110-00)
12
6
DIMENSIONAL DIAGRAM
TECHNICAL
SPECIFICATIONS
TRANSPORT
English
GENERAL DATA
Total weight: 340kg
Transportheight: 1,990mm
Dimensions:
Height: 1,990mm
Width: 866 mm
Depth: 680mm
Depth with open
door: 1,365mm
Recommended space for machine
in operation (working area):
Height: 1,990mm
Width: 2,066mm
Depth with open
door: 1,965mm
Loading aperture:
Height: 458 mm
Width: 704 mm
Bale size:
Height: approx.600mm
Depth: 500mm
Width: 700mm
Weight(paper): upto50kg
Weight(plastic): upto70kg
Noise level:
<62.3(±1.0)dB(A)(ISO11200&
11202)
Paint: Two-part paint and powder
coatwithphosphatisingasbase.
Colours:
Orange RAL2001
Grey RAL7032
ELECTRICAL DATA
Operating power: 230V,50Hz
Operating voltage: 24V
Electric motor: 1.1kW
Fuse rating: 10A
Protection class: IP 55
HYDRAULIC DATA:
Working pressure (paper): 115bar
Working pressure
(plastic): 90bar
Overload pressure: 140bar
Press force (paper): 4 tons
Press force (plastic): 3 tons
Surface pressure
(paper): 1.15kg/cm
2
Surface pressure
(plastic): 0.9kg/cm
2
Cycle time, total: 33 s.
Cylinder stroke length: 640mm
Oil volume: 6,2litres
Recommended oil:
+5°C to +60°C
ISOVG32-68,Mineraloil
Below +5°C
Aspecialoilorheatershouldbeused
atlowertemperatures.
Themachinehasa highcentre ofgravity.Thepress platemust befully lowered
whenthemachineismoved.
Manualmachine(MAN):Closetheshutter.Press‘Downarrow’onthecontrolpanel.
Automaticmachine(AUTO):Presstosettomanualmode(MAN)onthecontrolpanel.Close
theshutter.Press‘Downarrow’
