OSAKA – SMART BOX – Simple Manual – v1.1 – Page 2
2 OPERATION DUE TO HIGH OR LOW RELATIVE
HUMIDITY PERCENTAGE (Only if the F0 parameter
equals 5 5
2.1 Activate the operation due to high or low relative
humidity percentage e
1. Press the and keys for 4 seconds: The display will
show “rhL” (operation due to low relative humidity
percentage) or “rhH” (operation due to high relative humidity
percentage) for 10 seconds.
To go back to the normal display without having to wait:
2. Press any key.
Example: If the room’s ventilation is minimal (only the
compressor is ignited), the humidity is minimal since it
condenses in the evaporator.
However, if the ventilation is maximal (the fans are always
active) the humidity is higher since it distributes around the
room.
The parameters that ought to be considered are the F4 and
F5, consider the power of the fans, if they are very powerful
they could dehydrate the product.
2.2 See what operation mode is activated _
1. Press the and keys: The display will show “rhL”
(operation due to low relative humidity percentage) or “rhH”
(operation due to high relative humidity percentage) for 10
seconds.
To go back to the normal display without having to wait:
2. Press any key.
3 - “HACCP” OPERATION e
3.1 Show the HACCP alarms _
1. Press the key for 1 second: the display will show the
first variable that it’s available to be read.
2. Press the or keys to select “LS”.
3. Press the key to see the information.
4. Press the or keys to select (if it is present):
1. “AL” Minimum temperature alarm
2. “AH” Maximum temperature alarm
3. “id” Door switch alarm
4. “PF” Power Failure alarm (Only available in SMART
BOX SD and SMART BOX PLUS SD).
5. Press the key: the “HACCP” LED will turn off and the
screen will start showing the alarm’s information
consecutively and automatically, for instance:
1 “8.0” The critical value is 8.0 °C/8 °F
2 “Sta” the display will show the time and date of the
alarm (only available in SMART BOX SD and SMART
BOX PLUS SD).
3 “y16” Alarm’s year; in 2016
4 “n06” Alarm’s month; in June
5 “d26” Alarm’s day; the 26th
6 “h16” Alarm’s hour; 16
7 “n30” Alarm’s minute; 30
8 “dur” The display will show the alarm’s duration
9 “h01” Alarm’s hours; 1 h
10 “n15” Alarm’s minutes; 15 min.
To exit the process:
6. Press the key.
3.2 Delete the HACCP alarms _
1. Press the key for 1 second: the display will show the
first variable that it’s available to be read.
2. Press the or keys to select “rLS”.
3. Press the key.
4. Press the or keys to enter “149”.
5. Press the key or wait for 15 seconds: The display will
flash and show “- - -” for 4 seconds, then the device will exit
the process.
4 – DATA LOGGING IN COMPLIANCE WITH THE EN
128300NORM M
4.1 Activate the data logging "HACCP" operation modee
This operation mode is always activated.
4.2 Activate the “service” data logging operation mode_
1. Press the key for 1 second: the display will show the
first variable that it’s available to be read.
2. Press the or keys to select “SEr”.
3. Press the key.
4. Press the or keys to select “1”.
5. Press the key or wait 15 seconds: The display will flash
and show “SEr” for 4 seconds, then the device will exit the
process.
4.3 Show information of the data logger errors s
1. Press the key for 1 second: the display will show the
first variable that it’s available to be read.
2. Press the or keys to select “SEr”.
3. Press the key.
4. Press the or keys to select (if it is present):
1. “FUL” SD card storage is full.
2. “Sd” SD card not inserted or unrecognized.
3. “Pr7” auxiliary 2 temperature probe error
4. “Pr8” auxiliary 3 temperature probe error
5. “BAt” error in the data logger’s battery.
To exit the process
5. Press the key.
5 – OPERATION HOURS OF THE COMPRESSOR _
5.1 See the operation hours of the compressor _
1. Press the key for 1 second: the display will show the
first variable that it’s available to be read.
2. Press the or keys to select:
“CH1” operation hours of the compressor.
“CH2” operation hours of the compressor 2.
3. Press the key to see the operation hours.
To exit the process:
4. Wait without pressing anything for 60 seconds or press the
key.
5.2 Delete the operation hours of the compressor _
1. Press the key for 1 second: the display will show the
first variable that it’s available to be read.
2. Press the or keys to select “rCH”.
3. Press the key.
4. Press the or keys to enter “149”.
5. Press the key or wait for 15 seconds: The display will
flash and show “- - -” for 4 seconds, then the device will exit
the process.
