OSD Audio SMP100 User Manual

AUDIO
RMS Output Power ...................................................................................................... 80W/8Ω; 100W/4Ω
THD ............................................................................................................................................................
1%
Frequency Response .............................................................................................. 20Hz-160Hz +/-1dB
Signal to Noise ........................................................................................................................................95dB
Input Sensitivity ................................................................................................................................. 200mV
Crossover ...................................................................................................................................... 40-160Hz
Phase .................................................................................................................................................... 0-180°
GENERAL
Trigger Input ................................................................................................................... +12VDC to +24VDC
Line Voltage Range ................................................................................................ 110-120/220-240 VAC
Standby Power ......................................................................................................................................... 1.8W
Dimensions .............................................. 5.6”W x 1.8”H x 4.75” D (143mm W x 45mm H x 120mm D)
Overall Length (including knobs/connectors) ................................................................. 5.9” (150mm)
Weight .................................................................................................................................. 1.75lbs (0.79kg)
SPECIFICATIONS
WARRANTY
All OSD AUDIO electronics have (2) year Limited Warranty against defects in materials and workmanship. Proof of
purchase must accompany all claims. During the warranty period OSD AUDIO will replace any defective part and correct
any defect in workmanship without charge for either parts or labor
OSD AUDIO may replace returned electronics with a product of equal value and performance. In such cases, some
modifications to the mounting may be
necessary and are not OSD AUDIO’s responsibility.
For this warranty to apply, the unit must be installed and used according to its written instructions. If necessary, repairs
must be performed by OSD AUDIO. The unit must be returned to OSD AUDIO at the owner’s expense and with prior
written permission. Accidental damage and shipping damage are not considered defects, nor is damaged resulting from
abuse or from servicing performed by an agency or person not specifically authorized in writing by OSD Audio
OSD AUDIO sells products only through authorized dealers and distributors to ensure that customers obtain proper
support and service. Any OSD AUDIO product purchased from an unauthorized dealer or other source, including retailers,
mail order dealers and online sellers will not be honored or serviced under existing OSD AUDIO warranty policy. Any sale of
product by an unauthorized source or other manner not authorized by OSD AUDIO shall void the warranty on the
applicable product.
Damage to or destruction of components due to application of excessive power voids the warranty on those parts. In these
cases, repairs will be made on the basis of the retail value of the parts and labor. To return for repairs, you must email
customer service at RMA@audiogeargroup.com for a Returned Merchandise Authorization (RMA) number and must be
shipped to OSD AUDIO at the owner’s expense, along with a note explaining the nature of service required. Be sure to
pack the product(s) in a corrugated container with at least 3 inches of resilient material to protect the unit from damage in
transit.
This Warranty Does Not Cover: Damage caused by abuse, accident, misuse, negligence, or improper operation (installa-
tion) • Any products that have been altered or modified • Any product whose identifying number of decal, serial #, etc. has
been alte
OSD Audio | Brea, CA | osdaudio.com
SMP100 man. rev1 6/18
red, defaced or removed • Normal wear and maintenance.

OSD Audio SMP100 Specifications

Audio

RMS output power	80W/8Ω; 100W/4Ω
THD	1%
Frequency response	20Hz-160Hz +/-1dB
Signal to noise	95dB
Input sensitivity	200mV
Crossover	40-160Hz
Phase	0-180°

General

Trigger input	+12VDC to +24VDC
Line voltage range	110-120/220-240 VAC
Standby power	1.8W

Weight and Dimensions

Dimensions	5.6”W x 1.8”H x 4.75” D (143mm W x 45mm H x 120mm D)
Overall length	5.9” (150mm)
Weight	1.75lbs (0.79kg)
