OSD Audio SMP100 User Manual

90
35HZ
DIGITAL SUBWOOFER
A M PLIFI E R
SMP100
Adjusts the SMP100 audio output level to the connected subwoofer. Set to an
SMP100 Sub OUT.
AC power and turned ON.
One, green LED. Green LED illuminates when the SMP100 is connected to 1. POWER LED -
2. PHASE - The Phase setting allows compensation for subwoofer location relative to the
main speakers. Adjust the Phase setting to the point of highest sub audio output.
RANGE: 0º to 180 º.
3. CROSSOVER - The Crossover sets the frequency at which audio content will pass to the
RANGE: 35Hz to 160Hz.
4. VOLUME -
appropriate level for a smooth, natural sounding transition to extend and enhance the low
frequency output of the full-range speakers connected to Speaker Level OUT.
Front Panel Features
2 3 41
FRONT PANEL

OSD Audio SMP100 Specifications

Audio

RMS output power	80W/8Ω; 100W/4Ω
THD	1%
Frequency response	20Hz-160Hz +/-1dB
Signal to noise	95dB
Input sensitivity	200mV
Crossover	40-160Hz
Phase	0-180°

General

Trigger input	+12VDC to +24VDC
Line voltage range	110-120/220-240 VAC
Standby power	1.8W

Weight and Dimensions

Dimensions	5.6”W x 1.8”H x 4.75” D (143mm W x 45mm H x 120mm D)
Overall length	5.9” (150mm)
Weight	1.75lbs (0.79kg)
