Specifications
21
Chapter 5 Specifications
1. Product detailed information
Specification Values
Input characteristic
16 channels of 3G/HD/SD-SDI input
signals
one input
module with 16
input channels
Input module 3G/HD/SD-SDI input signal
Output
characteristic
4 channels of SDI/HDMI output signal
one output
module with 4
output channels
Output module SDI/HDMI output signal
Control Interface GPI/O, LTC, Ethernet, RS422 (TSL)
Display Units Up to 16 displays in a single screen
Control Software AURORA
Working
Environment
Work Temperature: 0~70
℃
Work Humility: 10%~90%(no condense)
Height: below 1000 feet (3048 meter) above sea level
Weight(fully
loaded)
1U,6.1kg 465.5(L)×342(W)×44(H)mm
Power
Consumption
100W
Electrical
Characteristics
100-240VAC, 50-60Hz, two redundant power modules
Signal Format NTSC, PAL
Signal Amplitude 1Vp-p+/-3dB
Impedance 75Ω
Return Loss >40 dB to 5 MHz
DC Offset 0V±0.05 V
Frequency
Response
±0.2 dB to 5 MHz
Differential Gain <1%
Differential Phase <1.5°
Video Standard
SMPTE 424M, SMPTE 292M, SMPTE 259M, SMPTE
297M
