0,7 mm
To access the sparkplug detach the upper section of the motorcy-
cle (see page 29). Once the upper cover has been removed, the
motorcycle’s electrical system can be accessed. Carefully but
firmly, pull away the hood that provides a current, leaving the upper
part of the sparkplug exposed. Using a special sparkplug key,
unscrew it.
The sparkplug should be checked regularly and a spare
sparkplug should be carried at all times in case it comes
off. The sparkplug can accumulate charcoal and dirt with
use. For this reason, it can be removed and cleaned so
that it lasts longer.
Observe the distance between the electrode and the
arch. This distance should be 0.7 mm.
NOTE: The sparkplug should not be handled if the
motorcycle is hot.
38 User manual
Sparkplug
