User manual 23
Control Pad
6
3
2
1
5
4
1 2
3 4
Control Pad
The control pad is located on the left handlebar, within reach of the
thumb. This control pad can be used to control the lights, indica-
tors, horn and engine stop.
See the image with information about the control pad.
1 – Position lights
2 – Cross lights
3 - Long range lights
4 – Lights for changing direction (left – right)
5 – Horn
6 – Button to switch off engine
See the image with information about the control pad.
1 – Pilot lamp for change of direction (left – right)
2 – Pilot lamp for cross lights
3 – Pilot lamp for long range lights
4 – Pilot lamp for footrest
