User manual 25
Rear suspension
R
C
The rear suspension is formed by a single shock absorber spring.
The pre-charge of this spring can be adjusted by turning the
toothed rings that dictate its direction.
The compression (C), extension (R) and spring pre-charge (see
Fig.) are adjustable in the rear shock absorber.
A special key is needed to adjust these toothed rings.
Adjustable rings for the spring pre-charge
