Chain – tension adjustments
User manual 39
The transmission chain transmits the engine’s movement to the
rear wheel. To ensure that is works correctly, it should be checked.
The axle has easily adjustable eccentrics for tensing
the chain and centring the wheel.
The chain tension should permit 2 cm of oscillation
in the chain tension adjuster.
The chain hook should be positioned in an opposite
direction to the gear, as can be seen in the photo.
