User manual 29
Upper Section
1
2
Remove the upper section. Stage 1
Remove the upper section. Stage 2
To access different parts of the motorcycle or the motorcycle’s
electrical system the upper section should be removed. This
section is made up of 2 parts that are screwed onto the chassis and
fitted together.
The first part of this section is located on the front above the fuel
tank. Next is the second part of this section which corresponds to
the seat area and rear mudguards.
* Model without standardisation kit
