25 Front brake handle
26 Throttle grip
27 Throttle grip mechanism
28 Front brake pump
29 Right fork stanchion regulator
30 OSSA multi-function box
31 Left fork stanchion regulator
32 Clutch pump
33 Lights control pad
34 Clutch handle
35 Headlights
14 User manual
Location of elements
25
26
27
28 29
30
32
31
33
34
35
*Model without standardisation kit
User manual 15
Multi-function box
The OSSA TR280i multi-function box and the indicator lights next
to it provide very useful information at all times.
The multi-function box is a power box system with an LCD screen
controlled by a console with indicator lights, located in the centre of
the handlebars.
The information displayed on the multi-function box includes: the
number of revolutions made by the engine, speed, distance
covered, total distance covered, time, average speed, maximum
speed, environmental temperature, running time and uptime.
This device has an internal memory unit that stores data like total
Km and total running time, even when it is switched off.
Some features may be personalised: the device can measure in
kilometres or miles. The wheel circumference value can also be
changed.
A temperature sensor warns us with a yellow light (1) when the
engine temperature is excessive.
Another sensor provides a warning with a red light (2) when the
rate at which the engine turns is excessive.
OSSA multifunction display
Temperature warning LED
Function Select Button
Right buttonLeft button
LED warning of
excessive motor rotation
