28 User manual
Fuel tank
The fuel tank forms a structural part of the chassis and
is located on the front inside part. To fill up with petrol,
open the fuel tank lid, situated on the upper part, by
unscrewing in an anti-clockwise direction.
The engine of this motorcycle uses a mixture of
unleaded petrol and 2T oil, 100% synthetic in a 0.9
proportion.
It’s recommended that a hose or funnel is used to fill
up to avoid spilling the petrol. This is especially
important if the motorcycle is hot. DO NOT fill up
with petrol when the motorcycle is turned on.
User manual 29
Upper Section
1
2
Remove the upper section. Stage 1
Remove the upper section. Stage 2
To access different parts of the motorcycle or the motorcycle’s
electrical system the upper section should be removed. This section
is made up of 2 parts that are screwed onto the chassis and fitted
together.
The first part of this section is located on the front above the fuel
tank. Next is the second part of this section which corresponds to
the seat area and rear mudguards.
* Model without standardisation kit
