8 User manual
Technical specifications
ENGINE
Cubic capacity 272.2 cc
Type Mono-cylindrical two inverted speeds with admission via slats directly to the sump
Cooling system Liquid
Diameter x stroke 70x60 mm
Power supply EFI Kokusan Battery-less System
Ignition CDI Kokusan digital magnetic steering
Clutch Hydraulic clutch knob
TRANSMISSION
Gear box 6 speeds
Transmission Primary by gears, secondary by chain
Engine lubrication Mix 0.9% Oil 100% synthetic
Changing lubrication and clutch 350 cc. of oil – type Gear Extreme 75 W
CHASSIS
Type Tube form in CR-MO steel, with pipe and lower part made from forged aluminium
Front suspension Fork with aluminium bars, 40 mm diameter Marzocchi adjustable in extension and compression
Rear suspension Variable progressive system with TTX OHlins mono shock absorber adjustable in extension and compression
Front brake 185 mm diameter disc with 4-piston brake caliper
Rear brake 150 mm diameter disc with 2-piston brake caliper
Front wheel 28 spokes with 2.75x21 wheel
Rear wheel 28 spokes with 4.00 x 18 tubeless wheel
Engine protector Constructed in AA7075 T6
Kick-start pedal Forged aluminium
Transmission and brake pedal Forged aluminium with retractable toe cap
User manual 9
Technical specifications
WEIGHTS AND MEASUREMENTS
Distance between axles 1.328 mm
Seat height 655 mm
Distance to the ground 340 mm
Fuel tank capacity 2,6 litres
Mass in service 64 kg
OSSA Factory reserves the right to make modifications without prior notification. Kokusan, Marzocchi, OHlins are registered trademarks and their use is licensed.
