16 User manual
Multi-function box
Technical features
Functions
Technical features
Accuracy
Symbol Increasess
Current speed 4 - 399,9 Km/h o M/hSDP 0,1 Km/h o M/h +/- 0,1%
0 - 19999 rpm
RPM
10 rpm +/- 0,1%
Tachometer
Distance covered
0,1 Km/h o M/h +/- 0,1%
0,0 - 19999 Km / M
DST
Maximum speed
MS
4 - 399,9 Km/h o M/h
0,1 Km/h o M/h +/- 0,1%
TT
Running time 0 - 9999 hours 59 minutes
1 second +/- 0,1%
0 - 12000 rpm
-
Variable +/- 0,1%
Tachometer bar
0,0 - 999999
ODO
1 Km +/- 0,1%
Mileage
1 minute
0 - 999 hours 59 minutes
RT
+/- 0,1%
Uptime
1 minute
0 - 9999 hours 59 minutes
ART
+/- 0,1%
Accumulated uptime
Each use
12:59:59 - 23:59:59
00:00:00
+/- 0,1%
Clock
Each use
1 year's duration approx
LO
+/- 0,1%
Battery low
0 - 3999 mm
-
- -
Tyre size
Input voltage: 9-400 V CA/CC.
Speed sensor: magnetic non-contact sensor
Tachometer input: electrical pulse sensor
Wheel circumference adjuster: 1 mm -3.999 mm (increases of 1 mm)
Running temperature / storage: from 0ºC to 60ºC (from 32ºF to 140ºF) / from -20ºC to 80ºC (from - 4ºF to 176ºF)
Battery / Life: 3V CR2032 / 1 year approx
User manual 17
Functions
RPM: Bar
Bar graph tachometer. The tachometer bar graph displays up to
12,000 rpm.
RPM: Digital tachometer
The RPM appear on the right side, on the second line. The digital
tachometer displays up to 12,000 rpm. The tachometer signal can
be captured from the sparkplug wire.
Warning of gear change due to rpm.
The rpm appear on the right side, on the second line. The digital
tachometer displays up to 12,000 rpm. The tachometer signal is
received from the sparkplug wire.
SPD: Speedometer
The speedometer information appears on the centre of the screen.
It displays up to 399.9 km/hour or miles/hour.
MS: Maximum speed meter
It displays the maximum speed reached during the last operation
after having set the counter at zero.
DST: Distance covered
It appears on the right side, on the second line of the screen. The
TRIP function records the mileage accumulated by the vehicle
since the last RESET.
ODO: Mileage counter
It records the distance or total accumulated mileage for the vehicle.
The data is stored in the memory, even when the device is switched
off.
ART: Running time controller
It calculates the total running time. It begins counting as soon as
the engine is switched on.
RT: Total running time controller
It calculates the vehicle’s running time from the last RESET. It
begins to count from when the vehicle starts to move. The data is
stored in the memory, even when the device is switched off.
12/24 hour clock
It displays the current time in 12 or 24 hour clock. It indicates the
temperature of the environment and engine. The display screen on
the upper left shows the environmental temperature. Using an
optional temperature sensor, the screen displays the engine
temperature. If excessive, the yellow light comes on.
Indicator that engine turn rate is excessive / Warning of gear change
due to rpm.
If the engine turn rate is excessive a second red warning light will
come on. This function acts as a warning to change gear when a
specific number of rpm is reached. The red light flashes when the
rpm reaches the established value and stops flashing when the
gear is changed.
Multi-function
