8.6 PB-46A Capstan Photo Amplifier P.C.B. Assembly
No. Description Part No. Notes
P.C.B. PB9A492A
Connector CN406055 EI Type Male 6P
Connector CN406064 EI Type Female 6P
Connector CN408057 EI Type Male 8P
Connector CN408066 EI Type Female 8P
Socket Contact CN7B-052
Check Pin CN901150 Orange
Check Pin CN901157 Black
VR101, VR102 Potentiometer RV424220 20 kΩ Duty Balance
MTR-90III Operation and Maintenance Manual
October 1990
Section 8 Printed Circuit Board Layouts and Parts Lists
8 - 9
