9.10 24CH Input/Output Assembly: ZA-95A
No. Description Part No. Notes
1 Panel, Amp Chassis Rear Panel ZA95A01
2 Panel, Output Transformer ZA92H02
3 Wire Assembly, Amp Control ZA-63A
4 Connector, XLR CN103046
5 Connector, XLR CN103045
6 Hinge, R CY2019
7 Hinge, L CY2020
8 Collar, Panel ZA91F08
9 Output Transformer Assembly ZA-53D Option
10 Angle, Input Trans P.C.B. Assembly ZA91G02 Option
11 P.C.B. Assembly, Input Transformer PB-77Z Option
12 P.C.B., Input Transformer PB9A501 (ZA-53C)
13 Transformer, Input TF21006
14 Connector CN403043 Option
15 Washer, Dress F540-4BN
16 Washer, Nylon KZ6C006
17 Plate, Nut A104412
MTR-90III Operation and Maintenance Manual
October 1990
Section 9 Exploded Views and Parts Lists
9 - 21
