Long PID Names
Long PID Names allows the user to enable/disable the tool scrolling
the complete PID name on the bottom line of the display while viewing
Live Data or viewing Freeze Data.
 From the System Setupmenu,usethe▲UPor▼DOWN
arrow keys until Long PID Names is highlighted, then press
ENTER.
 SelectONorOFFasdesiredusingthe▲UPor▼DOWN
arrow keys, then press
ENTER to save or BACK to
return to System Setup.
State OBD Check (Emissions)
The State OBD Check function is used to display a basic status of the
vehicle’s OBD system.
The State OBD Check function has the following areas:
 MIL STATUS ON or OFF
 Number of Codes Found
 Number of Monitors OK
 Number of Monitors Inc
 Number of Monitors N/A
9 State OBD Check should be done with the key on engine
running (KOER) due to showing MIL status.
9 The number of codes found are both Conrmed and
Permanent codes. Pending codes are not included.
9 The number of Monitors that are either OK, INC or NA are
only Since DTCs Cleared and not This Drive Cycle.
9 Refer to Read Codes and I/M Monitors for more detailed
information about the results.
