21
Tool Description
IAT Intake Air Temp
IAT 11, 21 Intake Air Temperature Sensor Bank 1 Sensor 1, Bank 2 Sensor 1
IAT 12, 22 Intake Air Temperature Sensor Bank 1 Sensor 2, Bank 2 Sensor 2
IAT 13, 23 Intake Air Temperature Sensor Bank 1 Sensor 3, Bank 2 Sensor 3
ICP_A, B Injection Control Pressure A, B
ICP_A_CMD, B_CMD Commanded Injection Control Pressure A, B
IDLE_TIME Total Idle Run Time
IGNADV Timing Advance
LAMBDA11, 21 02 Sensor Lambda Bank 1 Sensor 1, Bank 2 Sensor 1
LAMBDA12, 22 02 Sensor Lambda Bank 1 Sensor 2, Bank 2 Sensor 2
LT FTRM1 Long Term Fuel Trim 1 or 3
LT FTRM2 Long Term Fuel Trim 2 or 4
LT SEC FT1, 2, 3, 4 Long Term Secondary O2 Sensor Fuel Trim 1, 2, 3, 4
MAF, A, B Mass Air Flow, A, B
MAP, A, B Manifold Absolute Pressure, A, B
MIL DIST MIL_DIST
MIL STATUS Malfunction Indicator Lamp
MIL TIME Minutes Run by MIL activated
MST Manifold Surface Temperature
N/D_STAT Auto Trans Neutral Drive Status
N/G_STAT Manual Trans Neutral Gear Status
NNTE_Stat NOx NTE control area status
NOX 11, 21 NOx Sensor Concentration Bank 1 Sensor 1, Bank 2 Sensor 1
NOX 12,22 NOx Sensor Concentration Bank 1 Sensor 2, Bank 2 Sensor 2
NOXLEVELHI,HI1,HI2,
HI3, HI4
SCR inducement system actual state 10K history HI1 (0 - 10000 km),
10K history HI2 (10000 - 20000 km), 10K history HI3 (20000 - 30000
km), 10K history HI4 (30000 - 40000 km): NOx emission too high
NOX_ADS_DESUL NOx Adsorber Desulfurization Status
NOX_ADS_REGEN NOx Adsorber Regen Status
NWI_TIME Total Run Time by the Engien whicle NOx warning mode is activated
O2S O2VoltageorCurrentindicatesBank/Sensor
O2S11_PCT, O2S21_PCT 02 Sensor Concentration Bank 1 Sensor 1, Bank 2 Sensor 1
O2S12_PCT, O2S22_PCT 02 Sensor Concentration Bank 1 Sensor 2, Bank 2 Sensor 2
