14
|
Quick Start Guide English
575862 Rev B | 03.2016
Bosch Automotive Service Solutions Inc.
Function Menu Description
Long PID
Names
System Setup Allows the user to enable/disable
the tool scrolling the complete PID
name on the bottom line of the
display while viewing live data or
viewing freeze data.
MIL Status Global OBDII
Functions
Displays whether the Malfunction
Indicator Lamp is on or off.
Memory Test System Setup Checks RAM and Flash ROM.
Modules
Present
Global OBDII
Functions
Views the status of all OBD II com-
pliant modules.
O2 Monitor
Tests
Global OBDII
Functions
The O2 Monitor Tests is NOT an ON-
DEMAND TEST. This Function displays
oxygen sensor monitoring test results
from the vehicle’s memory.
On-Board
Systems
Global OBDII
Functions
Scan tool controls the operation of
vehicle components, tests or systems.
On Demand
Tests
Diagnostic Menu selection that provides the list
of On Demand Tests for the
selected vehicle.
Pre-Trigger
Setup
System Setup This function is used to configure
how many Pre-Trigger frames are
stored prior to beginning a recording.
Print Data Main, Diagnostic,
Datastream,
Diagnostic Codes,
Special Func-
tions, On Demand
Tests
Prints diagnostic information stored
in the Scan Tool. (Refer to Users
Manual)
