vehicle computer is telling the
MIL to illuminate when the
engine is running.
• MIL ON indicates that the
Malfunction Indicator Lamp
should be ON.
• MIL OFF indicates that the
Malfunction Indicator Lamp
should be OFF.
I / M Monitors (Emissions)
Inspection / Maintenance
Monitors provide a snapshot
of the Emission System opera-
tions by indicating that the
I / M Monitors are Ready or Not
Ready. For an I / M Monitor to
be Ready, the vehicle must have
completed a drive cycle (been
driven long enough under proper
conditions to have completed a
drive cycle). A Monitor must be
listed as Ready to pass an emis-
sions test. If an I / M Monitor is
Not Ready, it is because a drive
cycle has not completed.
The Tool will indicate Ready
(ok), Not Ready (inc), or Not
Applicable (n/a) for each I / M
Monitor. The Tool supports the
following I / M Monitors:
Monitor Expanded Name
Misfire Monitor Misfire Monitor
Fuel System Mon Fuel System Monitor
Comp Component
Comprehensive Compo
-
nents Monitor
Catalyst Mon Catalyst Monitor
Htd Catalyst Heated Catalyst Monitor
Evap System Mon
Evaporative System Mon
-
itor
Sec Air System
Secondary Air System
Monitor
A/C Refrig Mon
Air Conditioning Refriger
-
ant Monitor
Oxygen Sens Mon Oxygen Sensor Monitor
Oxygen Sens Htr
Oxygen Sensor Heater
Monitor
EGR/VVTSysMon
Exhaust Gas Recircula
-
tionorVariableValveTim-
ing Monitor
NMHC Cat Mon
Non-Methane Hydrocar
-
bon Catalyst
NOX Treat Mon Nitrogen Oxide Treatment
Boost Pres Mon Boost Pressure Monitor
Exhst Gas Sensr Exhaust Gas Sensor
PM Filter Mon Particulate Matter Filter
This is a complete list of I / M
Monitors supported by the Tool.
The number of Monitors read
by the Tool from your vehicle
may vary. A diesel vehicle, for
example, does not have an
Oxygen Sensor Monitor. As a
result, there will be no Oxygen
Sensor Monitor status for a die-
sel vehicle.
Two types of I / M Monitors
tests are:
