16 | Ottobock 3WR95
CAUTION
Incorrect use of the knee joint.
CAUTION
Risk of pinching where the joint bends.
4 Delivery
4.1 Scope of Delivery
5 Preparation for use
5.1 Alignment/assembly
The
residual limb position must be taken into account for positioning of the socket connection.
Perform alignment in 2 steps:
5.1.1 Basic alignment using the alignment tool
30 mm relative to the alignment reference line.
add 5 mm.
set the knee joint axis of rota-
tion (alignment reference point) 15 mm back from the alignment reference line.
