17
PREPARATION BEFORE INSTALLATION
INDOOR UNIT INSTALLATION DRAWING
The indoor unit may be mounted in three different ways:
Exposed
Floor lnstallation
Wall Installation
Half conceated
Mounting plate
Grid (field supply)
Molding
Concealed
REQUIRED INSTALLATION CLEARANCE DISTANCES DIAGRAM
59"(150 cm)
or more
59"(150 cm)
or more
59"(150 cm)
or more
59"(150 cm)
or more
6" (15 cm) or below
from the floor
