Outback Power Systems FX2024ET User Manual

32
Nominal DC Input Voltage Range 48VDC
Nominal AC Voltage / Frequency 230VAC / 50 HZ
Continuous Power Rating at 25C Ambient 2300VA
Continuous AC RMS Output at 25°C 10.0 Amps AC
Idle Power - Full AC Output ≈ 23 Watts DC
Idle Power - Search Mode 6 Watts DC
Typical E ciency 93.4%
Total Harmonic Distortion - Typical 2%
Output Voltage Regulation ± 2%
Maximum Output Current – Peak (1 mSec) 35 amps AC
Maximum Output Current - RMS (100 mSec) 25 amps AC
AC Overload Capability - Surge 5750VA
AC Overload Capability - 5 Second 4800VA
AC Overload Capability - 30 Minutes 3100VA
AC Input Current Maximum 30 Amps AC
AC Input Voltage Range 160 to 300VAC
AC Input Frequency Range 44.0 to 56.0 Hz
DC Input Range 42.0-68.0 VDC
DC Input Current – Rated Power 57.5 Amps DC
Continuous Battery Charger Output 30 Amps DC
FX2348ET
Nominal DC Input Voltage Range 12VDC
Nominal AC Voltage / Frequency 230VAC / 50 HZ
Continuous Power Rating at 25C Ambient 2600VA
Continuous AC RMS Output at 25°C 11.3 Amps AC
Idle Power - Full AC Output ≈ 20 Watts DC
Idle Power - Search Mode 6 Watts DC
Typical E ciency 90%
Total Harmonic Distortion - Typical 2%
Output Voltage Regulation ± 2%
Maximum Output Current – Peak (1 mSec) 28 amps AC
Maximum Output Current - RMS (100 mSec) 20 amps AC
AC Overload Capability - Surge 4600VA
AC Overload Capability - 5 Second 4000VA
AC Overload Capability - 30 Minutes 3100VA
AC Input Current Maximum 30 Amps AC
AC Input Voltage Range 160 to 300VAC
AC Input Frequency Range 44.0 to 56.0 Hz
DC Input Range 10.5-17.0 VDC
DC Input Current – Rated Power 260 Amps DC
Continuous Battery Charger Output 120 Amps DC
VFX2612E
