Outback Power Systems FX2024ET User Manual

33
VFX3024E
Nominal DC Input Voltage Range 24VDC
Nominal AC Voltage / Frequency 230VAC / 50 HZ
Continuous Power Rating at 25C Ambient 3000VA
Continuous AC RMS Output at 25°C 20 Amps AC
Idle Power - Full AC Output ≈ 20 Watts DC
Idle Power - Search Mode 6 Watts DC
Typical E ciency 90%
Total Harmonic Distortion - Typical 2%
Output Voltage Regulation ± 2%
Maximum Output Current – Peak (1 mSec) 35 amps AC
Maximum Output Current - RMS (100 mSec) 25 amps AC
AC Overload Capability - Surge 5750VA
AC Overload Capability - 5 Second 4800VA
AC Overload Capability - 30 Minutes 3300VA
AC Input Current Maximum 30 Amps AC
AC Input Voltage Range
160 to 300VAC
AC Input Frequency Range 44.0 to 56.0 Hz
DC Input Range 21.0-34.0 VDC
DC Input Current – Rated Power 150 Amps DC
Continuous Battery Charger Output 85 Amps DC
VFX3048E
Nominal DC Input Voltage Range 48VDC
Nominal AC Voltage / Frequency 230VAC / 50 HZ
Continuous Power Rating at 25C Ambient 3000VA
Continuous AC RMS Output at 25°C 13 Amps AC
Idle Power - Full AC Output ≈ 23 Watts DC
Idle Power - Search Mode 6 Watts DC
Typical E ciency 93%
Total Harmonic Distortion - Typical 2%
Output Voltage Regulation ± 2%
Maximum Output Current – Peak (1 mSec) 35 amps AC
Maximum Output Current - RMS (100 mSec) 25 amps AC
AC Overload Capability - Surge 5750VA
AC Overload Capability - 5 Second 4800VA
AC Overload Capability - 30 Minutes 3300VA
AC Input Current Maximum 30 Amps AC
AC Input Voltage Range 160 to 300VAC
AC Input Frequency Range 44-56 Hz
DC Input Range 42.0 to 68.0 VDC
DC Input Current – Rated Power 75Amps DC
Continuous Battery Charger Output 45 Amps DC
