OutBack Power Technologies MATE3 User Manual

900-0137-01-00 Rev A 9
Radian-Class Inverter Data Stream
This is the data stream generated for each “Radian-class” inverter connected to the system. (This includes all
variations of the GS inverter.)

The data stream for each inverter is 80 characters long.

An example is 00,6,00,00,00,00,119,000,119,00,00,00,00,121,000,121,04,000,02,554,128,000,067.

The matrix in Table 7 and the list in Table 8 define the data stream by character. Specific descriptions for
each category begin on page 11.
Table 7 Data Stream Matrix for Radian-Class Inverters
Start of Status Page Port Address separator Device Type 6 separator L1 Inverter current separator L1 Charger current separator L1 Buy current separator L1 Sell current separator L1 Grid input voltage separator L1 Generator input voltage separator L1 output voltage separator Error modes separator L2 Charger current separator L1 Charger current separator L2 Sell Current
ASCII
code
10 X X 44 54 44 X X 44 X X 44 X X 44 X X 44 X X X 44 X X X 44 X X X x X X 44 X X 44 X X X X
Char. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
L2 Sell Current separator L2 Grid input voltage separator L2 Generator input voltage separator L2 output voltage separator Inverter operating mode separator Error codes separator AC mode separator Battery voltage separator Misc separator Warning codes separator Checksum End of status page
ASCII
code
X 44 X X X X X X X 44 X X X 44 X X 44 X X X 44 X X 44 X X X 44 X X X 44 X X X 44 X X X 13
Char. 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
