OutBack Power Technologies MATE3 User Manual

900-0137-01-00 Rev A 5
FX-Class Inverter Data Stream
This is the data stream generated for each FX-class inverter connected to the system. This includes all variants
on the FX such as VFX, GTFX, GVFX, and so on.

The data stream for each inverter is 52 characters long.

An example is 00,2,00,00,00,119,000,00,00,000,01,254,008,000,033.

The items shown in Table 1 define the data stream by character. Specific descriptions for each category
begin on page 6.
Table 1 Data Stream Matrix for FX-Class Inverters
Character Definition Character Definition
1 New Line character, ASCII (10).
Denotes the start of the status page.
27 Tens digit of inverter operating mode.
2 Tens digit of Port number. 28 Units digit of inverter operating mode.
3 Units digit of Port number. 29 Comma, ASCII (44). Used as a data separator.
4 Comma, ASCII (44). Used as a data separator. 30 High digit of inverter Error status code.
5 Device type 2, ASCII (50). Indicates FX-class. 31 Middle digit of inverter Error status code.
6 Comma, ASCII (44). Used as a data separator. 32 Low digit of inverter Error status code.
7 Tens digit of Inverter current. 33 Comma, ASCII (44). Used as a data separator.
8 Units digit of Inverter current. 34 High digit of inverter AC mode.
9 Comma, ASCII (44). Used as a data separator. 35 Low digit of inverter AC mode.
10 Tens digit of Charger current. 36 Comma, ASCII (44). Used as a data separator.
11 Units digit of Charger current. 37 Tens digit of battery voltage.
12 Comma, ASCII (44). Used as a data separator. 38 Units digit of battery voltage.
13 Tens digit of Buy current. 39 Tenths digit of battery voltage.
14 Units digit of Buy current. 40 Comma, ASCII (44). Used as a data separator.
15 Comma, ASCII (44). Used as a data separator. 41 High byte of inverter Misc.
16 Hundreds digit of AC input voltage. 42 Middle byte of inverter Misc.
17 Tens digit of AC input voltage. 43 Low byte of inverter Misc.
18 Units digit of AC input voltage. 44 Comma, ASCII (44). Used as a data separator.
19 Comma, ASCII (44). Used as a data separator. 45 High digit of inverter Warning status code.
20 Hundreds digit of AC output voltage. 46 Middle digit of inverter Warning status code.
21 Tens digit of AC output voltage. 47 Low digit of inverter Warning status code.
22 Units digit of AC output voltage. 48 Comma, ASCII (44). Used as a data separator.
23 Comma, ASCII (44). Used as a data separator. 49 Hundreds digit of Checksum.
24 Tens digit of Sell current. 50 Tens digit of Checksum.
25 Units digit of Sell current. 51 Units digit of Checksum.
26 Comma, ASCII (44). Used as a data separator. 52 Carriage return, ASCII (13). Denotes the end of the
status page.
Start of Status Page
Port Address
separator
Device Type 2
separator
Inverter current
separator
Charger current
separator
Buy current
separator
AC input voltage
separator
AC output voltage
separator
Sell current
separator
Inverter operatiing
mode
separator
Error codes
separator
AC mode
separator
Battery voltage
separator
Misc
separator
Warning codes
separator
Checksum
End of status page
ASCII
code
10 X X 44 50 44 X X 44 X X 44 X X 44 X X X 44 X X X 44 X X 44 X X 44 X X X 44 X X 44 X X X 44 X X X 44 X X X 44 X X X 13
Character 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52
