Radian-Class Inverter Data Stream
10 900-0137-01-00 Rev A
Table 8 Data Stream Definitions for Radian-Class Inverters
Byte Definition Byte Definition
1 New Line character, ASCII (10). Denotes the
start of the status page.
41 Units digit of Sell current on line L2.
2 Tens digit of Port number.
42 Comma, ASCII (44). Used as a data separator.
3 Units digit of Port number.
43 Hundreds digit of AC output voltage on line L2.
4 Comma, ASCII (44). Used as a data separator.
44 Tens digit of AC output voltage on line L2.
5 Device type 6, ASCII (54). Indicates Radian-class.
45 Units digit of AC output voltage on line L2.
6 Comma, ASCII (44). Used as a data separator.
46 Comma, ASCII (44). Used as a data separator.
7 Tens digit of Inverter current on line L1.
47
Hundreds digit of AC input voltage on grid L2.
8 Units digit of Inverter current on line L1.
48
Tens digit of AC input voltage on grid L2.
9 Comma, ASCII (44). Used as a data separator.
49
Units digit of AC input voltage on grid L2.
10 Tens digit of Charger current on line L1.
50 Comma, ASCII (44). Used as a data separator.
11 Units digit of Charger current on line L1.
51 Hundreds digit of AC output voltage on line L2.
12 Comma, ASCII (44). Used as a data separator.
52 Tens digit of AC output voltage on line L2.
13
Tens digit of Buy current on line L1. 53 Units digit of AC output voltage on line L2.
14
Units digit of Buy current on line L1. 54 Comma, ASCII (44). Used as a data separator.
15
Comma, ASCII (44). Used as a data separator. 55 Tens digit of inverter operating mode.
16
Tens digit of Sell current on line L1. 56
Units digit of inverter operating mode.
17
Units digit of Sell current on line L1. 57
Comma, ASCII (44). Used as a data separator.
18
Comma, ASCII (44). Used as a data separator. 58
High digit of inverter Error code.
19 Hundreds digit of AC input voltage on grid L1.
59
Middle digit of inverter Error code.
20 Tens digit of AC input voltage on grid L1.
60
Low digit of inverter Error code.
21 Units digit of AC input voltage on grid L1.
61
Comma, ASCII (44). Used as a data separator.
22
Comma, ASCII (44). Used as a data separator. 62
High digit of inverter AC mode.
23
Hundreds digit of AC input voltage on
generator L1.
63 Low digit of inverter AC mode.
24
Tens digit of AC input voltage on generator L1. 64
Comma, ASCII (44). Used as a data separator.
25
Units digit of AC input voltage on generator L1. 65
Tens digit of battery voltage.
26
Comma, ASCII (44). Used as a data separator. 66
Units digit of battery voltage.
27
Hundreds digit of AC output voltage on line L1. 67
Tenths digit of battery voltage.
28
Tens digit of AC output voltage on line L1. 68 Comma, ASCII (44). Used as a data separator.
29
Units digit of AC output voltage on line L1. 69 High digit of inverter Misc.
30
Comma, ASCII (44). Used as a data separator. 70 Middle digit of inverter Misc.
31 Tens digit of Inverter current on line L2.
71 Low digit of inverter Misc.
32 Units digit of Inverter current on line L2.
72 Comma, ASCII (44). Used as a data separator.
33
Comma, ASCII (44). Used as a data separator. 73 High digit of inverter Warning code.
34 Tens digit of Charger current on line L2.
74 Middle digit of inverter Warning code.
35 Units digit of Charger current on line L2.
75 Low digit of inverter Warning code.
36
Comma, ASCII (44). Used as a data separator. 76 Comma, ASCII (44). Used as a data separator.
37
Tens digit of Buy current on line L2. 77 Hundreds digit of Chksum.
38
Units digit of Buy current on line L2. 78 Tens digit of Chksum.
39
Comma, ASCII (44). Used as a data separator. 79 Units digit of Chksum.
40
Tens digit of Sell current on line L2. 80 Carriage return, ASCII (13). Denotes the end of the
status page.
