Commands

18 900-0137-01-00 Rev A

Table 21 Command/Response Definitions

Command Response

<SELL:0> Set inverter Selling disabled

<SELL:1> Set inverter Selling enabled

<SELL:?> Returns current inverter sell mode [SELL:s]

s = state,

0=disabled,

1=enabled

<SELLV:nnn> Sets inverter selling battery voltage where nn.n is the selling voltage

<SELLV:+> Increments inverter selling battery voltage

<SELLV:-> Decrements inverter selling battery voltage

<SELLV:?> Returns the selling voltage [SELLV:nnn] when nn.n is the battery selling voltage

<CHG:0> Set the inverter’s charger(s) off

<CHG:1> Set the inverter’s charger(s) auto

<CHG:2> Set the inverter’s charger(s) on

<CHG:?> Returns current charger mode [CHG:m] for inverter

m = mode,

0=Off,

1=On,

2=Auto

<CHGLM:nn> Sets inverter’s AC charger limit amps, where nn = AC charger amp limit

<CHGLM:+> Increments inverter’s charger limits amps

<CHGLM:-> Decrements inverter’s charger limits amps

<CHGLM:?> Returns inverter’s AC charger limit amps [CHGLM:nn]

<AC1INLM:nn> Sets inverter’s AC1 input limit amps

<AC1INLM:+> Increments inverter’s AC1 input limit amps

<AC1INLM:-> Decrements inverter’s AC1 input limit amps

<AC1INLM:?> Returns inverter’s AC1 input limit amps [AC1INLM:nn]

<AC2INLM:nn> Sets inverter’s AC2 input limit amps

<AC2INLM:+> Increments inverter’s AC2 input limit amps

<AC2INLM:-> Decrements inverter’s AC2 input limit amps

<AC2INLM:?> Returns inverter’s AC2 input limit amps [AC2INLM:nn]

<BULK:1> Starts system wide bulk charge (all ports)

<BULK:2> Stops system wide bulk charge, ie goto float (all ports)

<BULK:?> Returns the current bulk charge state [BLK:s] (all ports)

s = state,

s=2 bulk charge stopped,

s=1 bulk charge enabled

<TEMP:p> Returns inverter’s internal temperatures, p = port 0-10, [TEMP:p,F,C,X]

where p = port 1-10, F=FET, C=CAP, X=Transformer temps in degrees C

If inverter is a Radian series, it returns [TEMP:p, 1st module F=FET, C=CAP, X=Transformer, 2nd

module F=FET, C=CAP, X=Transformer]

Example <TEMP:p> returns [TEMP:1:25,27,20,26,27,28]

<BTEMP:?> Returns battery temp value in degrees C [BTEMP:nnn] nnn in degrees C, can be a negative value

<ABSORBV:nnn> Sets system wide absorb voltage nn.n = absorb voltage (all ports)

<ABSORBV:?> Returns current system wide absorb voltage [ABSORBV:nnn] (all ports)

<ABSORBT:ttt] Set system wide absorb time in tenths of hours (all ports)

<ABSORBT:?> Returns system wide absorb time in tenth of hours [ABSORBT:ttt] (all ports)

<FLOATV:nnn> Sets system wide float voltage nn.n = float voltage (all ports)

<FLOATV:?> Returns current system wide float voltage [FLOATV:nnn] (all ports)

<FLOATT:ttt] Set inverter’s float time in tenths of hours (all ports)

<FLOATT:?> Returns inverter’s float time in tenth of hours [FLOATT:ttt] (all ports)

<FIRM:p> Returns firmware revision of software for device connected to port p [FIRM:V1.V2.V3]

<FIRM3:?> Returns MATE3 firmware revision [FIRM3:V1.V2.V3]
